P2 MINI
Payment POS
SUNMI P2 MINI
Reshape mini POS. Ultra-slim body, omni-channel payments.
More than payment.
Have your operations and management simplified.
Retail
VIP-level shopping experience.
Recommend bestsellers, check inventory and take
payments… offer your customers exclusive shopping
experience with P2 MINI.
Improved performance, low power consumption.
P2 MINI can do better, but consume less with a built-in quad-core 1.8GHz processor.
Professional 2D scan engine
1D/2D barcodes can be recognized even if they
are scratched, folded or stained.
are scratched, folded or stained.
HD dual cameras
5MP rear camera and 0.3 MP front camera,
open for your customization (optional).
open for your customization (optional).
TMS (Terminal Management System)
To meet clients’ needs in private deployment, SUNMI has launched a customized TMS
to secure data, improve management efficiency and reduce operating costs.
P2 MINI Tech Specs
Model Approved
T5810
OS
Android 9.0 Go
SUNMI OS
CPU
Quad-core Cortex-A53
1.8GHz/2.0GHz
Memory
1GB RAM+8GB ROM/
2GB RAM+16GB ROM
(Optional)
Display
5″ HD，1280*720，IPS
Capacitive Touch Screen,
multi-points Touch
Magcard Support
Support 1/2/3 track,
Support Bi-direction,
complies with ISO7810 / 7811 standards
IC Card Reader
Support smart IC card,
complies with ISO7816/
EMV/PBOC 3.0 standards
NFC Reader
PBOC 3.0, ISO/IEC 14443
TypeA&B, Mifare card,
Paypass, Paywave
PSAM Card Slot
PSAM Card slot, complies
with ISO7816 standard
Security
ANSI X9.8/ISO9564,
ANSI X9.9/ISO08731,
Master Key/Session Key,
Support 3DES
RSA, SHA-256, SM2, SM3,
SM4, etc.
Camera
Rear camera, 5.0MP, Flash,
AF, Support 1D/2D
barcode scan
Front camera, 0.3 MP fixed
focus, support 1D/2D
barcode payment(Optional)
Battery
Built-in Lithium polymer
battery, 3.8V/2500mAh
Communication
WiFi 2.4G/5GHz, IEEE 802.11
ac/a/b/g/n support,
Supports Hotspot I Bluetooth
5.0, support BLE 4G (TD-LTE/
FDD-LTE) + 3G (WCDMA) +
2G (GSM / GPRS)
Pogo Pin
8 x POGO Pin(Optional)
Peripheral Ports
1 x Type-C Supports
Charging USB 2.0, OTG
1 x 3.5mm Audio Jack
GPS
GPS, AGPS
Sensor
Gravity Sensor(Optional),
P/L sensor(Optional)
Buttons
Power on/off button,
Functional key*2
Speaker
1*Speaker 1W
Sim Card/ Micro SD Card Slot
Option 1:,
Dual SIM Card slot
Support1.8V/3.0V
Option 2:
Single SIM card slot and
Micro SD card slot(up to
32GB Max.)
Dimensions (L*W*H)
144x74x15mm
Weight
Main frame net weight:
200g
Environment
Operating temp.:
-10℃~50℃
Storage temp.:
-20℃~60℃
Certifications
PCI PTS 5.x, SRED I EMV L1 &
L2 I EMV Contactless L1 I
MasterCard Contactless
Visa payWave I MasterCard
TQM I ABECS I FCC I CE I
Anatel I RoHs I Discover D-PAS | JCB | AE
Supports and Downloads
Product Images
PNG(100MB)
Product Datasheet
Product Datasheet
Open Box Video
MP4(50MB)
